This is my personal guide to Flexbox

Picture of an open notebook Photo by Eugene Chystiakov on Unsplash

The Flexible Box Module, more commonly known as flexbox, was designed as a one-dimensional layout Module and a method for space distribution between items.

The main axis & the cross axis

The main axis is the axis running in the direction the flex items. are being laid out, either as rows or columns.
The cross axis runs perpendicular.

Flex container

An area of a document laid out using flexbox. To create a flex container, simply set the display property of the element to flex or flex-inline

Default behavior

1
2
3
4
5

Properties for the parent (flex container)

display: flex (default) | inline-flex

display: flex

Like the example above

display: inline-flex

1
2
3
4
5
flex-direction: row (default) | row-reverse | column (default) | column-reverse

flex-direction: row

1
2
3
4
5

flex-direction: row-reverse

1
2
3
4
5

flex-direction: column

1
2
3
4
5

flex-direction: column-reverse

1
2
3
4
5
flex-wrap: nowrap (default) | wrap | wrap-reverse

flex-wrap: nowrap

(default) all flex items will be on one line
1
2
3
4
5
6
7
8

flex-wrap: wrap

flex items will wrap onto multiple lines, from top to bottom
1
2
3
4
5
6
7
8

flex-wrap: wrap-reverse

flex items will wrap onto multiple lines from bottom to top
1
2
3
4
5
6
7
8
flex-flow: <flex-direction> <flex-wrap> this is shorthand for the flex-direction and flex-wrap properties e.g. flex-flow: column wrap;
justify-content: flex-start (default) | flex-end | center | space-between | space-around | space-evenly Defines the alignment along the main axis. There are more values for positional alignment, but they're not supported: start | end | left | right. And for overflow alignment, not supported either: safe | unsafe

justify-content: flex-start

1
2
3
4

justify-content: flex-end

1
2
3
4

justify-content: center

1
2
3
4

justify-content: space-between

1
2
3
4

justify-content: space-around

1
2
3
4

justify-content: space-evenly

1
2
3
4
align-items: flex-start | flex-end | center | stretch (default) | baseline Defines the behavior of the flex items along the cross axis

align-items: flex-start

1
2
3
4

align-items: flex-end

1
2
3
4

align-items: center

1
2
3
4

align-items: stretch

1
2
3
4

align-items: baseline

Notice the baseline of the numbers are aligned.
1

2

3

4

align-content: flex-start (default) | flex-end | center | space-between | space-around | stretch Aligns a flex container's lines within when there is extra space in the cross-axis. This property only takes effect on multi-line flexible containers.

align-content: flex-start

1
2
3
4
5
6
7
8

align-content: flex-end

1
2
3
4
5
6
7
8

align-content: center

1
2
3
4
5
6
7
8

align-content: space-between

1
2
3
4
5
6
7
8

align-content: space-around

1
2
3
4
5
6
7
8

align-content: stretch

1
2
3
4
5
6
7
8

Properties for the children (flex items)

order: <number> Changes the order of the items.
Item A: order: 3
Item B: order: 1
Item C: order: 2
Notice that items with no order property (D, E) are not affected.
A
B
C
D
E
flex-grow: <number> It accepts a unitless value that serves as a proportion. Dictates the amount of available space within the flex container the item should take up.
Item A: flex-grow: 3
Item B: flex-grow: 1
Item C: flex-grow: 2
Notice that items with no flex-grow property (D, E) are not affected.
A
B
C
D
E
flex: none | [ flex-grow flex-shrink? || flex-basis? ] This is a shorthand for flex-grow, flex-shrink and flex-basis combined.
It's recommended to use this shorthand version instead of setting individual values.
flex-shrink and flex-basis are optional.
align-self: auto | flex-start | flex-end | center | baseline | stretch Overrides the default vertical alignment (or the one set by align-items in the container) for flex items.
Works exactly like align-items but for a single flex item.

Item C: has align-self: flex-start;
The rest of the items are affected by align-items: flex-start;
A
B
C
D
E
